Stand Alone Photoelectric Smoke Detector YDS-H03


Features

  • Audible and easy to understand audio broadcasts for children and seniors.
  • Uses durable lithium battery.
  • Suitable for houses.
  • Equipped with an automatic test function, users would be notified of any faults immediately.
  • Ring-shaped with high brightness alarm indication, without any blind angles.
  • Easy to install without any wires. (wall-mounted type available)



Installing Location

  • In order to achieve optimum protection effectiveness, the detector can be installed in every individual room, such as the bedroom, kitchen, stairway, hallway, attic, living room, storage room and basement.
  • (If the length of the hallway or each individual room is more than 10 meters, it is recommended to install more than one voice alarm detector).

Model

YDS-H03

Operation Principle

 Smoke Detection

 Operating  concentration / temperature

 Smoke concentration 15%

Operating    State

 LED flashes and broadcasts alarm at the same time

Low Voltage

 If the voltage is under 2.69 V, it will chirp sounds  every 88 seconds as a reminder

Fault status

 If any fault is detected, it will keep playing the "fault"sound.

Power supply

 DC3V/Designated lithium battery

 ※Battery life might depend on the conditions of  use.

Sound output

 Over 80dB for 1m

Ambient temperature

 0℃~50℃

Dimensions

 102 mm (diameter) × 43 mm (high)

Weight

 Approx. 135 grams
